Jerr-Dan 7.5 Ton Aluminum (7TA)

When you need strength and reliability, turn to Jerr-Dan’s 7.5 Ton Aluminum carrier, which is exceptionally engineered to be strong and tough, and designed to utilize the full payload capacity of a single-rear axle chassis. With a 15,000 lb. capacity, the decks are available in widths of 96″ and 102″ and in lengths of 22′ and 24′, and are constructed of extruded floor planks. Jerr-Dan’s No-Lube™ slide pads and pivot joints on the subframe drastically reduce maintenance costs over the life of the carrier. They also provide best-in-class workmanship, paint finish and hose/harness tracking system. Discover for yourself how our exclusive patented Galvanized Steel Beam Technology™ provides unparalleled strength compared to any aluminum carrier design in the industry.

Winch Free Spool Control:

• Air (at both Control Stations)
• Dual Manual Free Spool (Option)

Wheel Lift - Lift Mechanism:

• 3,000 lb (Independent Raise and Lower)
• 4,000 lb (Independent Raise and Lower)
• 3,000 lb. (Zero Degree)

Tow Bar:

• 5000 lb. (Independent Raise and Lower)
• 3500 lb. (Manual Raise Lower)

Tow Options:

• Stationary 2" Reese Receiver
• Stationary Pintle Mounting Plate
• Independent Raise and Lower, Hydraulic Extend Ball Hitch
• Manual Raise and Lower, Hydraulic Extend Ball Hitch
• Manual Raise and Lower, Manual Extend Ball Hitch
• Independent Raise and Lower, Hydraulic Extend Pintle Plate
• Manual Raise and Lower, Hydraulic Extend Pintle Hitch
• Manual Raise and Lower, Manual Extend Pintle Hitch

• Subframe:

  • Painted
  • Galvanized
• Decking: Aluminum
• Deck Raised Rails: Fixed Aluminum Blade

• Deck Length:

  • 22 feet
  • 24 feet

• Deck Width:

  • 96 inches
  • 102 inches
• Winch: 10,000 lb. Worm

• Headboard:

  • Standard
  • Deluxe
  • Stationary
  • Side Recovery System

• Lightbar:

  • Amber LED
  • Red LED
• Hydraulic Deck Controls: Lighted, Dual (both sides)
• In-Cab Controls: Switch Panel
